8.0 Other settings
Menu 8.2.3 Stop el. heater
Here you select the outdoor temperature that auto-
matically blocks the immersion heater, i.e. the temper-
ature when additional energy is not used and the sys-
tem should switch to spring/autumn mode. The func-
tion only comes into force when Yes is selected in
menu 8.2.1. The value is adjustable between -5 °C and
set value for the circulation pump (10 – 25 °C) from
the menu 8.2.2.
12°C
Stop el. heater
8.2.3
U
N
Menu 8.2.4 Return
Return to Menu 8.2.0.
Return
8.2.4
Menu 8.3.0 Load monitor
Settings and readings regarding the load monitor are
set on the sub-menus to this menu.
Load monitor
8.3.0
Menu 8.3.8 Return
Return to Menu 8.3.0.
Return
8.3.8
Menu 8.3.3 Current phase 1
Shows the measured current from phase 1. If the val-
ue falls below 2.0 A Low is shown.
3.5 A
Current phase 1
8.3.3
Menu 8.3.4 Current Phase 2
Shows the measured current from phase 2. If the val-
ue falls below 2.0 A Low is shown.
3.3 A
Current phase 2
8.3.4
Menu 8.3.5 Current Phase 3
Shows the measured current from phase 3. If the val-
ue falls below 2.0 A Low is shown.
3.3 A
Current phase 3
8.3.5
Menu 8.3.6 Ratio of transf. EBV
The transfer value must be defined depending on the
current transformers used for the EBV card. The value
is adjustable between 100 and 900 in increments of
10. The setting 300 applies for the supplied current
transformers.
300
Ratio of transf. EBV
8.3.6
U
U
U
U
U
Menu 8.3.7 Tariff status
Shows the current tariff status.
Off
Tariff status
8.3.7
U
N
Menu 8.3.1 Fuse size
The setting selected on the EBV card (2) knob (100) is
shown here.
16 A
Fuse size
8.3.1
U
Menu 8.3.2 Max. el. power
The setting selected on the EBV card (2) knob (101) is
shown here.
Note: If a tariff is closed, only the allowed power is
shown here.
9.0 kW
Max. el. power
8.3.2
