Control
43
For the Installer
FIGHTER 360P
Menu 9.5 Return
Return to Menu 9.0.
Return
9.5
Menu 9.3.x.13 Relay status 1 8
Shows the relay status for relays 1-8 (relay 1 to the far
left) when the current alarm tripped.
0101 0011
Relay status 1-8
9.3.1.13
Menu 9.3.x.14 Relay status 9–14
Shows the relay status for relays 9-14 (relay 9 to the far
left) when the current alarm tripped.
0111 00
Relay status 9-14
9.3.1.14
Menu 9.3.x.15 Operating status
Shows the heat pump's operating status when the cur-
rent alarm tripped.
Operating status
9.3.1.15
Menu 9.3.x.16 Return
Return to Menu 9.3.x.0.
Return
9.3.1.16
Menu 9.3.7 Clear the alarm log
Select Yes to clear the alarm log.
NOTE! The setting returns to No as soon as the heat
pump has implemented the action.
Clear the alarm log
9.3.7
9.0 Service menu
Menu 9.3.8 Return
Return to Menu 9.3.0.
Return
9.3.8
Menu 9.4.0 Testing mode
Pressing the enter button takes you to sub-menus that
can be used during installation to check that the cor-
rect connection has been carried out.
Testing mode
9.4.0
Menu 9.4.1 Force control
When this menu is set to On, the user temporarily
takes control of the relays on the relay card. The set-
ting automatically returns to Off, 30 minutes after the
last button was pushed or after a restart.
Off
Force control
9.4.1
Menu 9.4.2 Relay 1 – 8
Shows the relay status for relays 1–8 (relay 1 to the far
left). It is possible to force the relay to the required
position using the enter button. The menu is only
shown when menu 9.4.1 is set to On.
1101 0100
Relay 1-8
9.4.2
Menu 9.4.3 Relay 9 – 14
Shows the relay status for relays 9–14 (relay 9 to the
far left). It is possible to force the relay to the required
position using the enter button. The menu is only
shown when menu 9.4.1 is set to On.
0110 10
Relay 9-14
9.4.3
Menu 9.4.4 Return
Return to Menu 9.4.0.
Return
9.4.4
NOTE!
Incorrect management of the menus below
can seriously damage the heat pump!
S
S
S
S
S
S
S
S
S
S
S
S
