Control
FIGHTER 360P
For the Installer
42
Menu 9.3.x.7 Temp. HW-sensor
Shows the temperature on the hot water sensor (83)
when the current alarm tripped.
52.7°C
Temp. HW-sensor
9.3.1.7
Menu 9.3.x.8 Temp. compr.sensor
Shows the temperature on the compressor sensor (94)
when the current alarm tripped.
49.1°C
Temp. compr.sensor
9.3.1.8
Menu 9.3.x.9 Temp. el. heat.sens.
Shows the temperature on the immersion heater sen-
sor (88) when the current alarm tripped.
51.3°C
Temp. el. heat.sens.
9.3.1.9
Menu 9.3.x.10 Evaporating temp.
Shows the evaporation temperature on the sensor (86)
when the current alarm tripped.
-0.1°C
Evaporating temp.
9.3.1.10
Menu 9.3.x.11 Vented air temp.
Shows the extract air temperature on the sensor (87)
when the current alarm tripped.
2.2°C
Vented air temp.
9.3.1.11
Menu 9.3.x.12 Exhaust air temp.
Shows the exhaust air temperature on the sensor (92)
when the current alarm tripped.
22.2°C
Exhaust air temp.
9.3.1.12
9.0 Service menu
S
S
S
S
S
S
Menu 9.3.x.1 Type of alarm
Shows which alarm has occurred, for example, HP-
alarm / TB-alarm, etc.
HP-alarm
Type of alarm
9.3.1.1
Menu 9.3.x.2 Date
Shows the date when the current alarm tripped.
2005-01-25
Date
9.3.1.2
Menu 9.3.x.3 Time
Shows the time when the current alarm tripped.
10:36
Time
9.3.1.3
Menu 9.3.x.4 Outdoor temperature
Shows the outdoor temperature on the sensor (15)
when the current alarm tripped.
4.3°C
Outdoor temperature
9.3.1.4
Menu 9.3.x.5 Flow temperature
Shows the flow temperature on the sensor (89) when
the current alarm tripped.
35.2°C
Flow temperature
9.3.1.5
Menu 9.3.x.6 Return temperature
Shows the return temperature on the sensor (93) when
the current alarm tripped.
31.0°C
Return temperature
9.3.1.6
S
S
S
S
S
S
