4.10.3.6.4 7210 SAS-R12 Console Port
The 7210 SAS-R12 is a service-aware IP MPLS-capable switch, suitable as an IP
MPLS and Carrier Ethernet access aggregation platform. The 7210 SAS-R12 can
aggregate 1G and 10G rings in access Ethernet networks. The platform supports full
line-rate redundant switching capacity, as well as MPLS and MPLS-TP based
service transport. It supports control-plane and switch fabric redundancy.
Figure 16 shows an example of the Console port on a 7210 SAS-R12 front panel.
Figure 16 Front Panel: 7210 SAS-R12 Console Port
Note: Refer to the 7210 SAS-R6 Chassis Installation Guide to know the IMMs supported.
hw0399
Note: Refer to the 7210 SAS-R12 Chassis Installation Guide for more information about the
supported IMMs.
