System Management
544
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
© 2021 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 17358 AAAB TQZZA
The no form of this command specifies that the software does not allocate any resources for
use by filter policies using ipv6 criteria with 64-bit IPv6 addresses. If no resources are
allocated for use, the software fails all attempts to associate a service entity (for example,
SAP and IP interface) with an ingress filter policy using this match criteria.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
If the user specifies max, the software allocates one chunk when the first SAP is
associated with an ingress filter policy using this match criteria. It continues to
allocate resources to SAPs associated with an ingress filter policy using this criteria,
as long as the total amount of resources allocated does not exceed the resources
allocated to ingress filter policies (configured with the config system resource-
profile ingress-internal-tcam acl-sap-ingress command) and chunks are
available for use.
Values Table 55 lists the parameter values.
mac-match-enable
Syntax mac-match-enable num-resources
no mac-match-enable
Table 55 Number of Resources Available for IPv6-64-Only-Match-Enable
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 5 max
7210 SAS-T Access-uplink mode (per node) 0 7 max
7210 SAS-T Network Mode (per node) 0 6 max
7210 SAS-R6 and 7210 SAS-R12 (per IMM) 0 5 max
7210 SAS-R6 and 7210 SAS-R12 IMM-c (per
IMM)
0 9 max
7210 SAS-Mxp (per node) 0 10 max
7210 SAS-Sx 1/10GE (per node)
(standalone)
060
7210 SAS-Sx 1/10GE (standalone-VC) 0 5 max
7210 SAS-S 1/10GE (per node) (standalone) 0 6 0
7210 SAS-S 1/10GE (standalone-VC) 0 5 max
7210 SAS-Sx 10/100GE (per node) 0 4 0
