System Management
560
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
© 2021 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 17358 AAAB TQZZA
• If the number of SAP aggregate meter resources allocated by user is less than the
number of resources requested by the user for ingress ACLs, then it allocates the
difference from the available global ingress CAM resource pool. For example, if the user
has allocated 1 chunk of 512 entries for SAP aggregate meters and then configures
ingress ACLs to use 2 chunks, the software will allocate 1 additional chunk (2 chunks
required for ingress ACLs - 1 chunk alloted to SAP aggregate meter) for use with ingress
ACLs. The meter resources associated with additional chunk alloted for ingress ACLs
can be assigned to the SAP aggregate feature, if need be.
Refer to the 7210 SAS-M, T, R6, R12, Mxp, Sx, S Quality of Service Guide and the
7210 SAS-M, T, R6, R12, Mxp, Sx, S Router Configuration Guide for more information about
use of SAP aggregate feature, ingress CAM resource allocation, and use of ACLs policies
respectively.
The no form of this command specifies that the software does not allocate any resources for
use by SAP ingress aggregate meter. If no resources are allocated for use, the software fails
all attempts to associate an aggregate-meter with SAP ingress.
Parameters num-resources — Specifies the maximum amount of resources for use by this filter
match criteria.
If the user specifies def, the software allocates the default amount of resources
based on the 7210 SAS platform. On 7210 SAS-R6 and 7210 SAS-R12, the amount
of default resources allocated also varies based on the IMM plugged into the slot.
Values Table 62 lists the parameter values and provides the values used for
def keyword on different 7210 SAS platforms and on different IMM
types.
Table 62 Number of Resources Available for SAP-Aggregate-Meter
Platforms Min value
(per node)
Max value
(per node)
Default
Values
7210 SAS-M (per node) 0 1 0
7210 SAS-T Access-uplink mode (per
node)
022
7210 SAS-R6 (per IMMv1) 0 4 2
7210 SAS-R6 and 7210 SAS-R12 (per
IMMv2)
043
7210 SAS-R6 and 7210 SAS-R12 (per
IMM-c)
043
7210 SAS-Mxp (per node) 0 4 3
7210 SAS-Sx 1/10GE (per node)
(standalone)
033
7210 SAS-Sx 1/10GE (standalone-VC) 0 3 2
