System Management
632
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
© 2021 Nokia.
Use subject to Terms available at: www.nokia.com
3HE 17358 AAAB TQZZA
Output The following output is an example of PTP unicast information, and Table 80 describes the
output fields.
Sample Output
*A:Dut-C# show system ptp unicast
===============================================================================
IEEE 1588/PTP Unicast Negotiation Information
===============================================================================
Router
IP Address Dir Type Rate Duration State Time
-------------------------------------------------------------------------------
100
10.0.0.1 Rx Announce 1 pkt/2 s 300 Granted 02/07/2014 16:52:35
10.0.0.1 Rx Sync 64 pkt/s 300 Granted 02/07/2014 16:52:39
10.0.0.1 Tx DelayReq 64 pkt/s 300 Granted 02/07/2014 16:52:39
10.0.0.1 Rx DelayRsp 64 pkt/s 300 Granted 02/07/2014 16:52:39
200
192.168.0.2 Tx Announce 1 pkt/2 s 300 Granted 02/07/2014 16:50:47
192.168.0.2 Tx Sync 64 pkt/s 300 Granted 02/07/2014 16:50:52
192.168.0.2 Rx DelayReq 64 pkt/s 300 Granted 02/07/2014 16:50:52
192.168.0.2 Tx DelayRsp 64 pkt/s 300 Granted 02/07/2014 16:50:52
-------------------------------------------------------------------------------
PTP Peers : 2
Total Packet Rate : 385 packets/second
===============================================================================
A:bksim1618# show system ptp router 1 unicast
===============================================================================
IEEE 1588/PTP Unicast Negotiation Information
===============================================================================
Router
IP Address Dir Type Rate Duration State Time
-------------------------------------------------------------------------------
1
10.2.1.20 Rx Announce 1 pkt/2 s 300 Granted 04/21/2013 19:14:19
10.2.1.20 Tx Announce 1 pkt/2 s 300 Granted 04/21/2013 19:13:25
10.2.1.20 Tx Sync 64 pkt/s 300 Granted 04/21/2013 19:13:30
10.2.1.20 Rx DelayReq 64 pkt/s 300 Granted 04/21/2013 19:13:30
10.2.1.20 Tx DelayRsp 64 pkt/s 300 Granted 04/21/2013 19:13:30
10.3.1.19 Rx Announce 1 pkt/2 s 300 Granted 04/21/2013 19:13:16
10.3.1.19 Rx Sync 64 pkt/s 300 Granted 04/21/2013 19:13:21
10.3.1.19 Tx DelayReq 64 pkt/s 300 Granted 04/21/2013 19:13:21
10.3.1.19 Rx DelayRsp 64 pkt/s 300 Granted 04/21/2013 19:13:21
-------------------------------------------------------------------------------
PTP Peers : 2
Total Packet Rate : 385 packets/second
===============================================================================
*A:bksim1618#
Table 80 Output Fields: PTP Unicast
Label Description
Router IP Address Displays the IP address of the router
