7. Click Next to start GSM1900 band TX IQ tuning.
8. ClickFinish and then Close.
Next actions
Tuning sliders should be close to the center of the scale after the tuning and within the limits specified in
the following table. If they are not within the limits, check Tx IQ quality manually.
Min Typ Max Unit
GSM850
I DC offset / Q DC
offset
-6 -4 6 %
Ampl -1 0 1 dB
Phase 85 90 95
°
GSM900
I DC offset / Q DC
offset
-6 -4 6 %
Ampl -1 0 1 dB
Phase 85 90 95
°
GSM1800/GSM1900
I/Q DC -6 0.5 6 %
Ampl -1 0 1 dB
Phase 95 100 110
°
Tx power level tuning (GSM)
Context
Because of variations at the IC (Integrated Circuit) process and discrete component values, the actual
transmitter RF gain of each phone is different. Tx power level tuning is used to find out mapping factors
called 'power coefficients’. These adjust the GSM transmitter output power to fulfill the specifications.
For EDGE transmission, the bias settings of the GSM PA are adjusted in order to improve linearity. This affects
the PA gain and hence the power levels have to be aligned separately for EDGE transmission.
Tx power level tuning has to be performed on all GSM bands.
Steps
1. Connect the phone to a spectrum analyzer.
2. Start
Phoenix
service software.
3. From the Operating mode drop-down menu, set mode to Local.
4. Choose Tuning→GSM→Tx Power Level Tuning .
RM-356
RF troubleshooting
Page 4 –40 COMPANY CONFIDENTIAL Issue 1
Copyright © 2008 Nokia. All rights reserved.
