Introduction
Phone description
RapidoYawe is the main digital baseband ASIC in the phone. It contains functionality for both WCDMA and
GSM EDGE.
Avilma is mainly the audio ASIC in the phone and Betty is basically the energy management controller for the
phone.
Bluetooth and FM radio are physically integrated in one single ASIC.
Key components
Function Description Item ref
Baseband ASIC Avilma
Betty
N2200
N2300
RF ASIC Ahneus N7505
Processor RapidoYawe D2800
Main camera accelerator Julie DM-500 N1400
PA GSM Front end module (FEM), quad band N7520
PA WCDMA N7540
Oscillators VCTCXO
32.768 kHz crystall oscillator
G7501
B2200
Memory 1Gb DDR DRAM + 2Gb M3 NAND Flash Combo D3000
Back-up battery RTC back-up battery 311 G2200
FM radio BTHFMRDS2.1M module D6000
Bluetooth BTHFMRDS2.1M module D6000
Battery BL-5J
Battery connector Tabby blade interface X2070
RF connector X7501
TV out TV out graphics engine D2480
Accelerometer N6501
GPS GPS ASIC GPS5350 N6200
WLAN WLAN module N6300
Touch screen controller
(TSC2004)
N2450
Digital Ambient Light
Sensor
N6502
RM-356
System Module and User Interface
Issue 1 COMPANY CONFIDENTIAL Page 6 –7
Copyright © 2008 Nokia. All rights reserved.
