Type Description
PKD-1/PK-1 SW security device
SS-62 Flash adapter base
Smart card reader
Measurement equipment
PC with Phoenix service software
Cables
CA-58RS RF service cable (product-specific adapter cable)
PCS-1 Power cable
DAU-9S MBUS cable
XRS-6 RF cable
20dB attenuator
Interface cable
USB cable
Bluetooth testing concept with SB-6
Figure 10 Service concept for RF testing and RF/BB tuning
Type Description
Product specific devices
FS-77 Flash adapter
RM-356
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –29
Copyright © 2008 Nokia. All rights reserved.
