Page #146 background image
NORDAC LINK (SK 250E-FDS ... SK 280E-FDS) Users Manual for Frequency Inverters as Field Distributors
146 BU 0250 en-3021
Pos: 464 /Anleitungen/ Elektronik/F U und Starter/5. Parameter/ Parameterauflis tung (P000 ...)/P500- P599/Parameter P546 Funk tion Bus-Sollwerte [SK 1x0E, SK 2xxE, SK 2 xxE-FDS] @ 2\mod_1346932172150_388. docx @ 43320 @ @ 1
P546 [-01]
...
[-03]
Function Bus setpoint
(Function of bus setpoint)
S P
0 ... 36
{ [-01] = 1 }
{ [-02] = 0 }
{ [-03] = 0 }
In this parameter, a function is allocated to the output setpoint during bus actuation.
NOTE:
For further details, please refer to the relevant bus manual or the description for
(P400). (Values from 0 % … 100 % correspond to 0000
hex
4000
hex
,)
For standardisation of the setpoint values: (chapter 8.8).
[-01] = Bus setpoint value 1 [-02] = Bus setpoint value 2 [-03] = Bus setpoint value 3
Possible values which can be set:
0 =
Off
13 =
Current limit, "Current limited"
1 =
Setpoint frequency (16 bit)
14 =
Current Switch-off
"Current switch-off limit"
2 =
Frequency addition
3 =
Frequency subtraction
15 =
Ramp time, (P102/103)
4 =
Minimum frequency
16 =
Lead torque, ((P214) multiplication)
5 =
Maximum frequency
17 =
Multiplication
6 =
Process controller actual value
18 =
Curve travel calculator
7 =
Process controller setpoint
19 =
Servo mode torque
8 =
Actual frequency PI
20 =
BusIO InBits 0-7
9 =
Actual freq. PI limited
21 =
...25 reserved, POSICON
10 =
Actual freq. PI monitored
31 =
Digital output IOE, sets the state of DOUT
of the first IOE
11 =
Torque current limit, "Torque current
limited"
32 =
Analogue output IOE, sets the value
AOUT of the first IOE), condition: P418 =
Function "31"
Value must be between 0 and 100 (0
hex
and 64
hex
). Otherwise the minimum value is
output at the analogue output.
12 =
Torque current switch-off,
"Torque current switch-off limit"
Pos: 465 /Anleitungen/ Elektronik/F U und Starter/5. Parameter/ Parameterauflis tung (P000 ...)/P500- P599/Parameter P546 Funk tion Bus-Sollwerte_Er gänzung [SK 2xxE, SK 2xxE-FDS ] @ 19\mod_1506006002157_3 88.docx @ 2366081 @ @ 1
33 =
Setpoint Torque processreg., "Setpoint
torque process controller"
34 =
d-correction F process
35 =
d-correction Torque
36 =
d-correction F+torque
Pos: 466 /Anleitungen/ Elektronik/F U und Starter/5. Parameter/ Parameterauflis tung (P000 ...)/P500- P599/Parameter P549 Funk tion Poti-Box [SK 1x0E, SK 2xxE, SK 2xxE-FDS] @ 2\mod_134 6932172758_388.doc x @ 43344 @ @ 1
P549
PotentiometerBox function
(PotentiometerBox function)
S
0 ... 16
{ 0 }
This parameter provides the possibility of adding a correction value (fixed frequency, analogue,
bus) to the current setpoint value by means of the SimpleBox/ParameterBox keyboard.
The adjustment range is determined by the auxiliary setpoint value P410/411.
0 = Off 2 = Frequency addition
1 = Setpoint frequency, with(P509) 1
control via USS is possible
3 = Frequency subtraction
Pos: 467 /Anleitungen/ Elektronik/F U und Starter/5. Parameter/ Parameterauflis tung (P000 ...)/P500- P599/Parameter P550 EEP ROM Kopierauftrag [S K 2xxE-FDS] @ 12\mod_146729314538 8_388.docx @ 335585 @ @ 1
