Nord Drivesystems SK 200E Series User Manual

3 Electrical Connection
BU 0210 en-3117 15
Size 4
Device type
SK 200E SK 210E SK 220E SK 230E
(SH) (ASI) (SH+ASI)
Pin
Labelling
1
43
24 V (output)
2
43
24 V (output)
3
40
GND
4
40
GND
5
-/84
/ ASI+
6
-/85
/ ASI-
7
11
10 V REF
8
14
AIN1+
9
16
AIN2+
10
12
AGND
11
44
24 V (input)
12
44
24 V (input)
13
40
GND
14
40
GND
15
21
DIN1
16
22
DIN2
17
23
DIN3
18
24/89
DIN4 24 V SH DIN4 24 V SH
19
40/88
GND 0V SH GND 0V SH
20
40
GND
21
1
DOUT1
22
40
GND
23
3
DOUT2
24
40
GND
25
77
SYS H
26
78
SYS L
27
38
TF+
28
39
TF-
Separate terminal block (2-pole):
1
79
MB+
2
80
MB+
