Nord Drivesystems SK 200E Series User Manual

6 Parameters
BU 0210 en-3117 69
P605 Absolute encoder S
Setting range
0 ... 16 Bit
Arrays
[-01] = Multi-turn resolution - number of possible encoder rotations
[-02] = Single-turn resolution - resolution per encoder rotation
Factory setting
{ all 10 }
Description
Resolution setting of the absolute encoder.
Note
If a single-turn encoder is used, the value "0" must be parameterised in Array [-01].
Before activation of the absolute encoder (P604) the resolution of the absolute
encoder must be correctly set in P605. Otherwise, values which are entered in
parameter P605 may be transferred to the absolute encoder.
Pos: 29 0 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 ...) /POS ICON/ Safet y/P60 0 bis P699 ( POSIC ON)/ P605 - Abs olutw ertge ber_Ei nstel lwert e @ 14\mod_1479740658322_388.docx @ 2306459 @ @ 1
Setting values
Conversion of encoder resolution (Bit value  decimal value):
Setting [Bit]
0
1
2
3
4
5
6
7
8
9
10
11
12
…
Resolution 1 2 4 8 16 32 64 128 256 512 1024 2048 4096 …
Example
– Absolute encoder with 12-bit single-turn resolution:
P605 [-01] = 0
P605 [-02] = 12
– Absolute encoder with 24-bit resolution, of which 12-bit single-turn resolution:
P605 [-01] = 12
P605 [-02] = 12
Pos: 29 1 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 600 bis P6 99 (POS ICON)/ P607 - Ü bers etz ung [ SK 2 xxE] @ 1 4\mod_1479741313115_388.docx @ 2306564 @ @ 1
P607 Speed ratio S
Setting range
- 65000 … 65000
Arrays
[-01] = Incremental encoder
[-02] = Absolute encoder
[-03] =
Setpoint / actual value
Factory setting
{ all 1 }
Description
Setting the speed ratio ( Section 4.5 "Speed ratio of setpoint and actual values")
Note
Also note parameter P608.
Pos: 29 3 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 600 bis P6 99 (POS ICON) /P60 8 - Untersetzung [SK 2xxE] @ 14\mod_1479742303826_388.docx @ 2306634 @ @ 1
P608 Reduction ratio S
Setting range
- 65000 … 65000
Arrays
[-01] =
Incremental encoder
[-02] =
Absolute encoder
[-03] =
Setpoint / actual value
Factory setting
{ all 1 }
Description
Setting the speed ratio ( Section 4.5 "Speed ratio of setpoint and actual values")
Note
Also note parameter
P607
.
Pos: 29 5 /Anlei tung en/El ektr onik/FU und Star ter/5 . Par ameter/ Par ameter aufli stung (P000 .. .)/POS ICON/ Saf ety/P 600 bis P6 99 (POS ICON) /P60 9 - Offset Posi tion [SK 2 xxE] @ 14\ mod_1479742897550_388.docx @ 2306809 @ @ 1
P609 Offset Position S
Setting range
- 50000,000 … 50000,000 rev.
Arrays
[-01] =
Incremental encoder
[-02] =
Absolute encoder
Factory setting
{ all 0 }
Description
Offset setting for absolute and relative position specification.
