3. Programming Program Change – Level One
44
AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002
Program Change – Level One
When the correct password is entered, the control panel will enter ‘Level One’ program mode. In this
mode, the trouble relay is activated and the System Trouble LED flashes and cannot be changed to
steady and the panel sounder is off. The following display will appear:
Clear
The Clear function is useful when the control panel is first installed, before autoprogramming. Pressing
the 0 key clears all general system programming options described in "System Edit" on page 49, and all
programmed addressable devices from the nonvolatile memory of the control panel. Before executing
the Clear command, the display will prompt the user to press the
ENTER
key to verify the command
before the system actually clears programming data.
Note: It is necessary to autoprogram the control panel after using the clear function.
Autoprogram
The first time the system is brought on-line, it must be autoprogrammed. Pressing the 1 key enters the
Autoprogramming mode. The main purpose of autoprogramming is to allow the installer a fast and easy
way to bring the system on-line as quickly as possible.
Note: Autoprogram is also the only way to add or delete devices.
Once Autoprogram is selected, the control panel automatically polls all devices installed/wired to the
SLC. The control panel communicates with each individual addressable device and displays the type of
device at each address location starting with detectors and then modules.
While autoprogramming the system, the control panel will display the following:
Verification of each device address and type installed on the SLC may now occur. If information is
correct, press the
ENTER
key to save the device in the program; if incorrect, press the left arrow key to
delete the device. In addition, adjective and noun descriptors plus zone assignments may be added to the
display field per device address. If the
SYSTEM
RESET
key is pressed at this time or the control panel is
allowed to time-out after 10 minutes of inactivity, a “System Corrupted” message will appear. Be
certain to step through all devices, using the
ENTER
or left arrow key.
The first time that autoprogramming is selected, all points installed on the SLC are identified. Default
device type (monitor, smoke detector, control) and software zone assignments for each device are
displayed. On any successive enabling of the autoprogram feature, the LCD display only displays the
newly installed, deleted, or changed devices on the SLC.
Devices which match the program already in memory are not changed and are not shown to the
operator. Devices which do not match the program (not the same address and/or type) are shown to the
operator. Devices inadvertently set to the same address are identified and displayed on the screen.
0=CLR 1=AUTO 2=POINT
3=SYS 4=PWORD 5=LOAD
AUTOPROGRAM
PLEASE WAIT
