MCTRL660 PRO Independent Controller
User Manual
5 Hardware Structure
www.novastar.tech
8
Type
Input
DVI IN

Single-link DVI connector

Custom resolutions supported:
Maximum width: 3840 pixels
Maximum height: 2560 pixels

Supported standard resolutions:
1024×768@(24/30/48/50/60/72/75/85/100/120)Hz
1280×1024@(24/30/48/50/60/72/75/85)Hz
1366×768@(24/30/48/50/60/72/75/85/100)Hz
1440×900@(24/30/48/50/60/72/75/85)Hz
1600×1200@(24/30/48/50/60)Hz
1920×1080@(24/30/48/50/60)Hz
1920×1200@(24/30/48/50/60)Hz
2560×960@(24/30/48/50)Hz
2560×1600@(24/30)Hz
HDMI IN

HDMI 1.4a compliant

HDCP 1.4 compliant

Custom resolutions supported:
Maximum width: 3840 pixels
Maximum height: 2560 pixels

Supported standard resolutions:
1024×768@(24/30/48/50/60/72/75/85/100/120)Hz
1280×1024@(24/30/48/50/60/72/75/85)Hz
1366×768@(24/30/48/50/60/72/75/85/100)Hz
1440×900@(24/30/48/50/60/72/75/85)Hz
1600×1200@(24/30/48/50/60)Hz
1920×1080@(24/30/48/50/60)Hz
1920×1200@(24/30/48/50/60)Hz
2560×960@(24/30/48/50)Hz
2560×1600@(24/30)Hz
3G-SDI IN

SMPTE ST 425-1 Level A & B, SMPTE ST 274, ST 296, ST 295
compliant

Maximum supported input resolution: 1920×1080@60Hz
Note: 3G-SDI input sources do not support input resolution settings.
Output
RJ45 × 6

6 Gigabit Ethernet ports

Maximum loading capacity of a single Ethernet port:
− For 8-bit input sources: 650,000 pixels
− For 10-bit/12-bit input sources: 320,000 pixels

Support redundancy between Ethernet ports.
