MCTRL660 PRO Independent Controller
User Manual
5 Hardware Structure
www.novastar.tech
9
OPT1
OPT2

10G optical ports
− Single-mode twin-core fiber: Support LC optical connectors;
wavelength: 1310 nm; transmission distance: 10 km;
OS1/OS2 recommended.
− Dual-mode twin-core fiber: Support LC optical connectors;
wavelength: 850 nm; transmission distance: 300 m;
OM3/OM4 recommended.

The maximum loading capacity of a single optical port equals to
that of all the 6 Ethernet ports.

2 OPT inputs/outputs
− The OPT1 works as the primary input or output port, and the
6 Gigabit Ethernet ports work as the corresponding output or
input ports.
− The OPT2 works as the backup input or output port of OPT1.

In the sending card mode, both OPT ports and 6 Gigabit Ethernet
ports can work as output ports to output the same image.

In the fiber converter mode, when the OPT ports work as the
input ports, the 6 Gigabit Ethernet ports work as output ports.
When the 6 Gigabit Ethernet ports work as input ports, the OPT
ports work as output ports.
DVI LOOP
DVI loop output
HDMI LOOP
HDMI loop output
Support HDCP 1.3 loop output encryption.
3G-SDI LOOP
SDI loop output
MONITOR
HDMI
Connect to a monitor to monitor the inputs. The output resolution of
this connector is 1920×1080@60Hz (fixed output with a width of
1920 pixels and height of 1080 pixels).
If the input resolution exceeds the monitor resolution, the input will
be automatically scaled in proportion and then displayed on the
monitor starting from its top left.
Control
GENLOCK IN
GENLOCK input connector

Genlock type: Blackburst

Input Genlock sync signal to ensure synchronization and same
refresh rate between the output signals of cascaded MCTRL660
PRO units and the external Genlock input signal.
GENLOCK LOOP
Genlock loop output connector. Up to 8 MCTRL660 PRO units can
be cascaded.
ETHERNET
Fast Ethernet port, which connects to PC and supports TCP/IP
USB IN
Input port for cascading devices, or connecting to PC
USB OUT
Output port for cascading devices. Up to 8 MCTRL660 PRO units
can be cascaded.
Power supply
100 V–240 V AC
Power switch
ON/OFF
