APPENDIX C: HDD INSTALLATION
APPENDIX C
HDD Installation
The following procedures illustrate hard disk drive (HDD) installation in a DVR9004N, and DVR9008N/DVR9016N without an HDD. If
you purchased your DVR without a HDD, or you want to upgrade the HDD installed in your DVR, use this procedure as a guideline.
C.1 DVR compatible HDDs
For the best performance of your system, install only an HDD from the following list in your DVR.
Table 2. DVR Compatible HDDs
Manufacturer Model Number Size (GB) Drive Interface
Western Digital®
WD5001ABYS 500 SATA
WD5000AVVS 500 SATA
WD7500AACS 750 SATA
WD10EADS 1000 SATA
WD15EADS 1500 SATA
WD20EADS 2000 SATA
Hitachi®
HDS721075KLA330 750 SATA
HDT721010SLA360 1000 SATA
Maxtor® 6V16010 160 SATA
Seagate®
ST3250310SV 250 SATA
ST3500320SV,
ST3500320AS
500 SATA
ST31000528AS 1000 SATA
ST31500341AS 1500 SATA
Samsung
SM
HD161HJ 160 SATA
HD501LJ 500 SATA
C.2 DVR9004N HDD Installation
The DVR9004N will accommodate only one internal HDD. The HDD bolts to the chassis with four screws inserted up through the
underside of the chassis.
