DOME
Transport and unpacking
EN - 11
6
4
3
6
TYPE
2
ALI GROUP SRL
A SOCIO UNICO
Viale Lombardia, 33
46012 BOZZOLO (MN)
ITALY
V
Hz
kW
A
5
MAX
Nr
Made in ITALY
COD.
3
1
2.5 - IDENTIFICATION OF THE COMPO-
NENTS (Fig. 4)
1. Data plate
2. Baking chamber with walls in refractory material
equipped with independent armoured heating ele
ments on the ceiling and the floor.
3. Oven support
4. Control panel
5. Chamber access door
6. Chimney
2.6 - IDENTIFICATION OF THE MACHINE (Fig. 4)
The serial number and identification data of the machine
are punched on a plate (1) fastened to the machine base.
IMPORTANT
The machine serial number should be al-
ways mentioned in your request of techni-
cal assistance or in your spare part orders.
FIG. 4
