DANGER
All operations described in this chapter
shall be carried out by skilled and author-
ized technicians, only.
3.1 - UNIT LIFTING (Fig. 1)
Lift the unit through a suitable device, such as a crane
or an hoist, complying with the following instructions:
• Unscrew the screws (1) and remove the top covering
that blocks the stones (2). (Fig.1)
• Remove the first stone (3) and do the same with
the other stones counterclockwise, until you have
removed them all. (Fig.2)
• Hook 4 ropes to the eyebolts (4) on the oven and the
orher end to the forks of the forklift adjusted according
to the weight of the oven.
• Lift the oven making sure it is balanced. (Fig. 3)
