2 – 12
Group Item Selections
Ribbon Selection Black Ribbon, Black, Yellow,
Magenta, Cyan, Violet, Orange,
Green
Printhead Gap 0, +1, -1
Adjust
Graphics Speed Low, High
Centering Position DEFAULT, MODE1,
MODE2 (591 only)
Parallel I/F I-Prime Buffer Print, Buffer Clear,
Invalid
Pin 18 +5V, Open
AutoFeed XT Invalid, Valid
(EPSON only)
Serial I/F Parity None, Odd, Even
(when
installed)
Serial Data 8 Bits, 7 Bits
7- or 8- Bits
Protocol Ready/Busy, XON/XOFF
Diagnostic Test No, Yes
Busy Line SSD-, SSD+, DTR, RTS
Baud Rate 9600 BPS, 4800 BPS, 2400 BPS,
1200 BPS, 600 BPS, 300 BPS,
19200 BPS
DSR Signal Valid, Invalid
DTR Signal Ready on Power Up,
Ready on Select
Busy Time 200 ms. 1 sec
CSF Bin 1 Line Spacing 6 LPI, 8 LPI
(when CSF
option is
installed)
