4 – 5
Character Table Decimal Hex ASCII Comp
Set Character Table 27 40 116 Ln 1B 28 74 Ln ESC ( t Ln E2
Hn Pn1 Pn2 Pn3 Hn Pn1 Pn2 Pn3 Hn Pn1 Pn2 Pn3
Ln and Hn: Length of the following parameters calculated by
Ln + Hn x 256.
(MSB of Hn is ignored.)
Normally Ln = 3, Hn = 0.
0 - Pn1, Pn2, Pn3 - 255 (Each MSB is ignored.)
Raster Graphics Decimal Hex ASCII Comp
Set Raster Graphics Mode 27 40 71 1B 28 47 ESC ( G E2
Ln Hn Pn Ln Hn Pn Ln Hn Pn
Ln and Hn: Length of the following parameters calculated by
Ln + Hn x 256.
(MSB of Hn is ignored.)
Normally Ln = 1, Hn = 0.
0 ≤ Pn1, Pn2, Pn3 ≤ 255 (Each MSB is ignored.)
This command sets raster graphics mode by Pn = 1(01H) or 0 (30H). The ESC .
(1B 2E) raster graphics command is only valid in this mode.
Pn2 Pn3 Character table
0 0 Italics
1 0 PC437 (USA)
3 0 PC850 (Multilingual)
7 0 PC860 (Portugal)
8 0 PC863 (Canada-French)
9 0 PC865 (Norway)
