3 – 33
Graphics Fine Line Spacing
Line feed/line spacing Value of n
n
/216 24
n
/360 20
n
/360 40
Epson
The line feed direction commands determine the platen movement of subsequent line
feed commands. The line feed direction backwards command reverses the normal
direction of the line feed commands. Any line feed command which follows the line
feed direction backwards command is acted upon as though it were a reverse line feed
command; a reverse line feed command initiates a forward line feed.
The line feed direction forward cancels this reversal of movement, and all subsequent
line feeds commands are acted upon in the normal manner.
Use the reverse line feed command to move the paper up in
n
/180 inch increments. The
paper will not advance beyond the top of form position.
