3 ā 3
Italic printing is slanted (e.g. OKI) and is used to lend emphasis to phrases, sentences
or entire paragraphs.
Italics Decimal Hex ASCII Comp
Begin italics 27 52 1B 34 ESC 4 E
End italics 27 53 1B 35 ESC 5 E
Begin italics 27 37 71 1B 25 47 ESC % G P A
End italics 27 37 72 1B 25 48 ESC % H P A
If you intend to print an entire document in italics, you may choose to select this
printing style in Menu Select mode.
Use the outline and shadow effects to produce more interesting and stylish headings.
They can be combined together as well as with emphasised and /or enhanced printing
for an even more striking effect.
Note: Outline and shadow printing commands can only be used for
printing characters, they cannot be used to print line graphics.
Character pitch, or width, is measured in Characters Per Inch (CPI). For example, at
10 CPI, each character is
1
/10 inch wide. The double width and compressed printing
commands interact with the basic pitches listed above to produce a range of character
widths. See the Character Width table below for all possible widths.
Outline and Shadow Decimal Hex ASCII Comp
Begin outline 27 113 1 1B 71 01 ESC q SOH E P A
Begin shadow 27 113 2 1B 71 02 ESC q STX E P A
Begin shadow and outline 27 113 3 1B 71 03 ESC q ETX E P A
Cancel shadow and/or outline 27 113 0 1B 71 00 ESC q NUL E P A
ā
Character Pitch Decimal Hex ASCII Comp
Begin 10 CPI (Pica) 27 80 1B 50 ESC P E
Begin 12 CPI (Elite) 27 77 1B 4D ESC M E
Begin 10 CPI (Pica) 18 12 DC2 P A
Begin 12 CPI (Elite) 27 58 1B 3A ESC : P A
Begin 15 CPI 27 103 1B 67 ESC g E P A
