3 ā 41
Note: The following commands are active only when the optional Cut
Sheet Feeder is installed on the printer.
This command feeds a sheet of paper from the CSF to the top of form position. If paper
is already in the printer, the printer will eject the page and load another.
This command prints data in the print buffer and ejects the page.
With these commands you can select the bin from which the paper will be fed, if you
have a dual bin CSF. If you are working with a Dual Bin Cut Sheet Feeder you can use
the following commands to select between the bins:
A separate TOF can be set for each of the bins on the CSF. This enables you to print
on letter-headed paper, fed from one bin, leaving a large margin, followed by printing
on pages fed from the other bin with a smaller margin.
Insert page Decimal Hex ASCII Comp
Insert page 27 25 73 1B 19 49 ESC EM I E P A
Eject page Decimal Hex ASCII Comp
Eject page 27 25 82 1B 19 52 ESC EM R E P A
Select bin Decimal Hex ASCII Comp
Select bin 1 27 25 49 1B 19 31 ESC EM 1 E P A
Select bin 2 27 25 50 1B 19 32 ESC EM 2 E P A
Cut sheet feeder control Decimal Hex ASCII Comp
Cut sheet feeding 27 91 70 1B 5B 46 ESC [ F P A
n1 n2 m1 n1 n2 m1 n1 n2 m1
m2 m3 m2 m3 m2 m3
n1 n2: number of parameters n1 + n2 * 256
m1: paper feeding method
m2: reserved
m3: bin number
