3 – 42
p1 = length of data (MSB is invalid).
These commands select the factory setup and menu defaults as shown above, then
initialize the printer.
Pno = Length of the following parameters (MSB is invalid).
This changes the current menu setting and parameters as follows:
Pan bit6 = 1 (fixed)
MSB is invalid
40H (C0H) <= Pa <= 7FH (FFH)
Pbn bit6 = 0 (fixed)
MSB is invalid
00H (80H) <= Pa <= 3FH (BFH)
n1 and n2 are the length bytes, normally n1 = 3 and n2 = 0.
m1 defines paper feeding method; m2 is always set to 1; m3 defines the bin number.
m1 = 1 Set manually inserting mode
m1 = 3 Set CSF mode
m3 = 0 No change
m3 = 1 Bin 1
m3 = 2 Bin 2
Print Raster Graphics Decimal Hex ASCII Comp
Factory setup 27 16 2 p1 data 1B 10 02 p1 ESC DLE STX p1 E P A
data data
Change the current Decimal Hex ASCII Comp
menu setting
Change the current 27 16 68 1B 10 44 ESC DLE D E P A
menu setting Pno Pa1 Pb1 Pno Pa1 Pb1 Pno Pa1 Pb1
Pa2 Pb2 ... Pa2 Pb2 ... Pa2 Pb2 ...
Pan Pbn Pan Pbn Pan Pbn
Change the current 27 16 69 1B 10 45 ESC DLE E E P A
gap setting Pno Pa1 Pb1 Pno Pa1 Pb1 Pno Pa1 Pb1
Pa2 Pb2 ... Pa2 Pb2 ... Pa2 Pb2 ...
Pan Pbn Pan Pbn Pan Pbn
