3 – 40
Epson
The ESC > command sets the most significant bit (MSB) of an 8-bit data input to 1.
The ESC = command sets the MSB to 0. ESC # cancels MSB control established by
either ESC > or ESC = and all data is interpreted exactly as sent from the computer.
After the printer has received one of the commands to begin print suppress mode, it
ignores all data until it receives the DC1 command. The SEL light will blink when the
printer is in print suppress mode.
Print suppress mode Decimal Hex ASCII Comp
Begin print suppress mode 19 13 DC3 E
Begin print suppress mode 27 81 n 1B 51 n ESC Q n P A
n = 1: Begin half speed printing n = 0: Begin full speed printing
Begin print suppress mode 27 106 1B 6A ESC j P A
End print suppress mode 17 11 DC1 E P A
Paper-Out Override
Any time you want to disable the paper-out switch to keep the printer printing to the
very bottom of the page, enter:
Emulation Mode
This command will change the emulation of the printer to the specified mode.
n = 00H IBM PPR emulation n = 40H Epson LQ emulation
01H Trapped 41H Epson LQ emulation
02H IBM PPR emulation
03H IBM AGM emulation
Paper out sensor Decimal Hex ASCII Comp
Paper out sensor OFF 27 56 1B 38 ESC 8 E P A
Paper out sensor ON 27 57 1B 39 ESC 9 E P A
Emulation mode Decimal Hex ASCII Comp
Emulation mode 27 123 n 1B 7B n ESC { n E P A
