5238-E P-87
SECTION 6 OFFSET FUNCTION
Program 4
LE33013R0300800120007
Program 4:
In this program, a tool looping similar to that performed in program 3 is executed with the numeral
values modified to avoid overcutting.
LE33013R0300800120008
This program almost yields the expected finish. However, there are still latent problems, such as:
• overcutting is caused depending on the size of the tool nose R
• the length of side N31 - N32 cannot be readily found.
These problems are solved by looping the tool path along a square as explained next.
Program 5
Program 5 solves the problems encountered with program 4.
LE33013R0300800120009
Imaginary shape
X+
N4
Z+
N31
N3
N32
N2
N1
N1
N2
N3
N31
N32
N4
G42
G00
G01
G01 X100
X120
X126
X120
Z100
Z80
Z40
Z43
Z20
F0.2 S1500
S1000
T010101 M03
X+
Z+
Imaginary shape
Portion left uncut
N31
N32
N3
N33
N2
N1
N4
