5238-E P-312
SECTION 12 USER TASK
[Program Sequence]
(1) Assume that there are a number of pulleys with a similar contour, shown as above. To simplify
the programs of these pulleys, express the contour of part A using variables.
(2) Program the pulley groove cutting cycle as a subprogram using the variables.
Since this program is called for after execution of axis motion command(s), it is prepared in
incremental mode so that it can be used wherever it is called.
The subprogram file name is "PULL-PTTN1.SUB".
Variable
Name
Contents
Numerical Value for
This Example (Fig. 3-1)
PC11 Pitch between the pulley groove 20 mm
XH1 Height of pulley groove 15
XD1 Starting point of cutting 2
ZW1 Width of groove 16
ZW2 Taper amount of groove in Z-axis direction 4.7
TW1 Width of cutting off tool 6
D1 Value of l of 1R 0.299
DK Value of K of 1R 0.954
To Next Page
