256
Chapter 9 Function setup
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
Adjustment Enhancement Mode
position
[Mode1], [Mode2], [Mode3], [OFF] Initial mode of enhancement
Mode 1
Mode 2
Mode 3
[A1] - [A8], [B1] - [B8], [E1] - [E8] Setting of each
enhancement mode
The default settings are:
Mode 1: A1
Mode 2: A3
Mode 3: A5
Color setting Color mode [Mode 1], [Mode 2], [Mode 3],
[Mode 4]
Color tone of the monitor
Image size Image size Scope 1 [Medium], [Full-height
] The display area size of the
endoscopic image
Scope 2 [Small
], [Medium]
Scope 3 [Medium
], [Full-height]
Scope 4 [Medium], [Full-height
]
Brightness Brightness
setting
Iris [Auto
], [Peak] Initial method of metering
Iris auto [AUTO 1
], [AUTO 2], [AVE] Metering method for “Auto”
Iris speed [High], [Medium
], [Low] Speed of the automatic
brightness control
Iris L [1], [2
], [3] Fine-tuning of “Iris Speed”
Iris D [1], [2
], [3] Fine-tuning of “Iris Speed”
AGC [ON
], [OFF] AGC function ON or OFF
Contrast [Normal
], [Low], [High] Initial setting of contrast
Exposure
area
[Mask
], [Center], [Full] Setting of the metering area
Electronic
shutter
[ON
], [OFF] Electric shutter function ON
or OFF
Display Display Save data [YES
], [NO]
Scope
nickname
[Enable], [OFF
] The display function of the
scope nickname is ON or
OFF.
Release
index time
[OFF], [2 sec], [4 sec
], [Always] Setting of display time of the
index image
Special light [Enable
], [Disable] The display function of the
special light observation is
ON or OFF.
Orientation [Normal
], [Rotation] Setting of the orientation of
the image
Setup item Setting value Note
Table 9.53
To Next Page
