Chapter 9 Function setup
257
EVIS EXERA II VIDEO SYSTEM CENTER CV-180
PinP PinP setting Size [1/4], [1/9] Image size of the sub image
Position [Upper-left], [Upper-right],
[Lower-left
], [Lower-right]
Position of the sub image
Movement [ON/OFF], [Mode change
]
Mode [SCOPE/aux.
], [AUX./scope] Setting of main and sub
Special
Light
PDD setting PDD gain [PDD1
], [PDD2] Initial method of PDD
NBI
enhancement
Mode
position
[Mode 1], [Mode 2
], [Mode 3], [OFF] Initial mode of enhancement
Mode 1
Mode 2
Mode 3
[A1] - [A8], [B1] - [B8], [E1] - [E8] Setting of each
enhancement mode
The default settings are:
Mode 1: A1
Mode 2: A3
Mode 3: A5
Setup item Setting value Note
Table 9.53
