Rear of CV-1500 ~ Remote terminal ~
20
[Devices that can be connected].
・・・ Observation monitor and insufflation system
for endoscopes
・・・ US center and flushing pumps for
endoscopy
・・・ Color video printers, etc.
・・・ Keyboard, etc.
・・・ CV interface converter
・・・ External video system center
1
2
4 5
3
6
The main remote terminals used for wiring are as follows:
[Remote Terminals]
1: MONITOR/UCR terminals.
2: EUS/OFP terminals.
3 : Printer output terminals
4 : Keyboard Terminals
5 : Adapter Terminals
6 : CV-LINK terminals.
