5-7 Multi-function Output Variables
5
 MX2 only
 RX only
LOC Low current signal R C021 to C026  43
IRDY Operation ready R C021 to C026  50
FWR Forward run signal R C021 to C026  51
RVR Reverse run signal R C021 to C026  52
MJA Fatal fault signal R C021 to C026  53
WCO Window comparator FV R C021 to C026  54
WCOI Window comparator FI R C021 to C026  55
Function variable Description R/W Reference
FREF Frequency command source R C001 to C007  58
REF RUN command source R C001 to C007  59
SETM Motor 2 selection R C001 to C007  60
EDM Safety device monitor R C001 to C007  62
Function variable Description R/W Reference
IP Signal during momentary power interruption R C021 to C026  08
O2Dc Analog FE disconnection detection R C021 to C026  29
LOG 4 Logic operation output 4 R C021 to C026  36
LOG 5 Logic operation output 5 R C021 to C026  37
LOG 6 Logic operation output 6 R C021 to C026  38
WCO2 Window comparator FE R C021 to C026  56
Function variable Description R/W Reference

Omron 3G3MX2 Series Specifications

General

Frequency Range	0.1 to 400 Hz
Control Method	V/f Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Safety Standard	CE, UL, cUL
IP Rating	IP20
Output Voltage	3-phase 200-240V AC
Output Frequency	0.1 to 400 Hz
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault, Short circuit
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Braking Unit	Built-in
Communication	Modbus RTU
Communication Interface	RS-485
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload
