Omron 3G3MX2 Series User Manual

9 LX inverter
9 - 16
Drive Programming User’s Manual (I580-E2)
Note The A052 parameter must be set to value 03 (Drive Programming) for the command to become effective.
9-5-2 Inverter Control Commands
UP
Command Description Argument
Makes the inverter start a forward operation.
This command is a shortcut of the “func  value”
command which is previously set as “UP :  1”.
---
Format
Flowchart method Text language method

UP :  1
DWN
Command Description Argument
Makes the inverter start a reverse operation.
This command is a shortcut of the “func  value”
command which is previously set as “DWN : 
1”.
---
Format
Flowchart method Text language method

DWN :  1
Accel
Command Description Argument
Sets the inverter acceleration time.
This command is a (Assign) command whose
left-hand side is set to the acceleration time
variable ACCEL.
Unit: 10 ms
Value: any variable or constant
(range 1 to 360,000)
Format
Flowchart method Text language method

ACCEL :  <value>
UP :  1
DWN :  1
ACCEL :  <value>

Omron 3G3MX2 Series Specifications

General

Frequency Range	0.1 to 400 Hz
Control Method	V/f Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Safety Standard	CE, UL, cUL
IP Rating	IP20
Output Voltage	3-phase 200-240V AC
Output Frequency	0.1 to 400 Hz
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault, Short circuit
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Braking Unit	Built-in
Communication	Modbus RTU
Communication Interface	RS-485
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload
