Omron 3G3MX2 Series User Manual

6 Drive Programming Commands
6 - 58
Drive Programming User’s Manual (I580-E2)
6-9 Inverter Control Commands
Run FW
Command Description Argument
Makes the inverter start a forward operation.
This command is a shortcut of the “func  value”
command which is previously set as “FW :  1”.
---
Format
Flowchart method Text language method

FW :  1
Run RV
Command Description Argument
Makes the inverter start a reverse operation.
This command is a shortcut of the “func  value”
command which is previously set as “RV :  1”.
---
Format
Flowchart method Text language method

RV :  1
Stop FW
Command Description Argument
Makes the inverter decelerate to stop from a for-
ward operation.
This command is a shortcut of the “func  value”
command which is previously set as “FW :  0”.
---
Format
Flowchart method Text language method

FW :  0
Stop RV
Command Description Argument
Makes the inverter decelerate to stop from a
reverse operation.
This command is a shortcut of the “func  value”
command which is previously set as “RV :  0”.
---
Format
Flowchart method Text language method

RV :  0
FW :  1
RV :  1
FW :  0
RV :  0

Omron 3G3MX2 Series Specifications

General

Frequency Range	0.1 to 400 Hz
Control Method	V/f Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Safety Standard	CE, UL, cUL
IP Rating	IP20
Output Voltage	3-phase 200-240V AC
Output Frequency	0.1 to 400 Hz
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault, Short circuit
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Braking Unit	Built-in
Communication	Modbus RTU
Communication Interface	RS-485
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload
