4 Drive Programming Editor
4 - 24
Drive Programming User’s Manual (I580-E2)
4-9 Transferring and Verifying Programs
Program transfer and verification are possible between the inverter and the Drive Programming func-
tion of the CX-Drive. At the same time, you can also execute parameter transfer and verification.
The created programs are compiled (program-checked) and transferred (downloaded) to the inverter if
there is no error.
From the [Drive] Menu, select [Transfer]- [To Drive] to transfer (download) data.
The programs and parameters in the inverter are transferred (uploaded) to the Drive Programming.
From the [Drive] Menu, select [Transfer]- [From Drive] to transfer (upload) data.
The Drive Programming programs and parameters are compared with the data in the inverter.
From the [Drive] Menu, select [Transfer] - [Compare with Drive] to execute verification.
From the [Drive] Menu, select [Transfer] - [Selection To Drive] to transfer (download) the selected data.
From the [Drive] Menu, select [Transfer] - [Selection From Drive] to transfer (upload) the selected data.
Transfer (from PC to Inverter)
Transfer (from Inverter to PC)
Verification (between PC and Inverter)
Partial Transfer (from PC to Inverter)
Partial Transfer (from Inverter to PC)

Omron 3G3MX2 Series Specifications

General

Frequency Range	0.1 to 400 Hz
Control Method	V/f Control, Sensorless Vector Control
Overload Capacity	150% for 60 seconds
Safety Standard	CE, UL, cUL
IP Rating	IP20
Output Voltage	3-phase 200-240V AC
Output Frequency	0.1 to 400 Hz
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground fault, Short circuit
Ambient Temperature	-10 to 50°C
Operating Temperature	-10 to 50°C
Storage Temperature	-20 to 65°C
Humidity	5% to 95% RH (non-condensing)
Altitude	Up to 1000 m
Braking Unit	Built-in
Communication	Modbus RTU
Communication Interface	RS-485
Cooling Method	Forced air cooling
Enclosure Rating	IP20
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload
