Omron 3G3MX2 Series - Drive Programming Editor; Executing a Program

9 - 5
9 LX inverter
Drive Programming User’s Manual (I580-E2)
9-3 Drive Programming Editor
9
9-3-1 Executing a Program
9-3 Drive Programming Editor
You execute the program by setting the inverter parameter, the Drive Programming Function Selection
(F025).
Once the program reaches "end" command after a series of processes was completed, the program is
not executed unless it is restarted.
To repeat the program, create a loop program so that the program does not reach “end” command.
9-3-1 Executing a Program
Parameter
No.
Function name Data Description
F025 Drive Programming
Function Selection
00: Disabled (default setting) Disables the Drive Programming function.
Programs are not executed.
If you change the setting to 00 (Disabled)
during program execution, the program
will be stopped.
01: Enabled
(Start/stop at power on/off)
Starts the Drive Programming program
automatically after the inverter power sup-
ply is turned on.
If you change the setting to 01 (Enabled)
while the program is stopped, the program
will be started.
F026 Drive Programming
RUN Trigger Selection
00: TRM (“PRG” terminal) Drive Programming program will run by
terminal. Set terminal to PRG function.
01: PARAM (setting F025 =
enable)
Drive Programming program will run if
F025 = enable
C001 to
C007
Multi-function Input S1
to S7 Selection
76: PRG
(Drive Programming start)
When the Drive Programming Function
Selection (F025) is set to 01 (Enabled:
Start/stop at power on/off), the program is
started via the multi-function input terminal
with this setting.
