Omron CJ - PROGRAMMING MANUAL 12-2009 - Page 126

86
Timer and Counter Instructions
Section 3-4
MULTI-OUTPUT
TIMER
MTIM
543
(BCD)
MTIMX
554
(Binary)
(CS1-H, CJ1-H,
CJ1M, or CS1D
only)
Output
Required
COUNTER
CNT
(BCD)
CNTX
546
(Binary)
(CS1-H, CJ1-H,
CJ1M, or CS1D
only)
Output
Required
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution condition
MTIM(543)
D1
D2
S
D1: Completion
Flags
D2: PV word
S: 1st SV word
0
SV 7
SV 2
SV 1
SV 0
0
to
to
Timer input
Timer PV (D2)
to
Completion
Flags (D1)
Bit 7
to
Timer PV
Timer SVs
Bit 2
Bit 1
Bit 0
MTIM(543)/MTIMX(554) operates a 0.1-s incrementing timer with 8
independent SVs and Completion Flags. The setting range for the
set value (SV) is 0 to 999.9 s for BCD and 0 to 6,553.5 s for binary
(decimal or hexadecimal).
MTIMX(554)
D1
D2
S
D1: Completion
Flags
D2: PV word
S: 1st SV word
CNT
N
S
N: Counter
number
S: Set value
Reset
input
Count
input
SV
Count input
Counter PV
Completion
Flag
Reset input
CNT/CNTX(546) operates a decrementing counter. The setting range
for the set value (SV) is 0 to 9,999 for BCD and 0 to 65,535 for binary
(decimal or hexadecimal).
CNTX(546)
N
S
Count
input
Reset
input
N: Counter
number
S: Set value
