6-5 Using a Scheduled Interrupt as a High-precision Timer
(CJ1-H-R and CJ1M Only)
When using a CJ1-H-R or CJ1M CPU Unit, the following functions allow a
scheduled interrupt to be used as a high-precision timer.
• The scheduled interrupt timer can be input in units of 0.1 ms (high-preci-
sion interval timer).
• Resetting (i.e., restart) is possible using the MSKS(690) instruction (fixed
time to first interrupt).
• Internal timer PVs can be read using the MSKR(692) instruction (interval
timer PV reading)
These functions allow applications such as that shown in the following exam-
ple of a high-precision one-shot timer, where the input bit turning ON acts as a
trigger, causing the output bit to turn ON, and then turn OFF again after a
fixed interval.
Instruction name BCD mode Binary mode
Mnemonic CNTR CNTRX
S (counter set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting 0 to 9,999 times 0 to 65,535 times
Instruction name BCD mode Binary mode
Mnemonic CNR CNRX
Instruction name BCD mode Binary mode
Mnemonic TIMW TIMWX
S (timer set value) #0000 or# 9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic TMHW TMHWX
S (timer set value)
Unit: 0.01 s
#0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.01 s) 0 to 999.9 s 0 to 655.35 s
Instruction name BCD mode Binary mode
Mnemonic CNTW CNTWX
S (counter set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting 0 to 9,999 times 0 to 65,535 times
