Omron CJ - PROGRAMMING MANUAL 12-2009 - Page 360

320
Changing the Timer/Counter PV Refresh Mode Section 6-4
TENTH-MS TIMER (CJ1-H-R CPU Units Only)
HUNDREDTH-MS TIMER (CJ1-H-R CPU Units Only)
ACCUMULATIVE TIMER (100 ms)
LONG TIMER (100 ms)
MULTI-OUTPUT TIMER (100 ms)
COUNTER
Instruction name BCD mode Binary mode
Mnemonic TIMU TIMUX
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.0001 s) 0 to 0.9999 s 0 to 6.5535 s
Instruction name BCD mode Binary mode
Mnemonic TMUH TMUHX
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.00001 s) 0 to 0.09999 s 0 to 0.65535 s
Instruction name BCD mode Binary mode
Mnemonic TTIM TTIMX
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic TIML TIMLX
S, S+1 (timer set values) #00000000 to #99999999
(BCD)
&0 to &4294967295 (deci-
mal)
or #0000 to #FFFFFFFF
(hexadecimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic MTIM MTIMX
S to S-7 (each timer set
value)
#0000 to #9999 (BCD) &0 to &65535
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic CNT CNTX
S (counter set value) #0000 to #9999 (BCD) &0 to& 65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting 0 to 9,999 times 0 to 65,535 times
