Omron CJ - PROGRAMMING MANUAL 12-2009 - Interrupt Control Instructions

134
Interrupt Control Instructions
Section 3-18
3-18 Interrupt Control Instructions
GLOBAL SUB-
ROUTINE CALL
(CS1-H, CJ1-H,
CJ1M, or CS1D
only)
GSBS
750
Calls the subroutine with the specified subroutine number and exe-
cutes that program.
Output
Not required
GLOBAL SUB-
ROUTINE ENTRY
(CS1-H, CJ1-H,
CJ1M, or CS1D
only)
GSBN
751
Indicates the beginning of the subroutine program with the specified
subroutine number.
Output
Not required
GLOBAL SUB-
ROUTINE
RETURN (CS1-H,
CJ1-H, CJ1M, or
CS1D only)
GRET
752
Indicates the end of a subroutine program. Output
Not required
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution condition
SET INTERRUPT
MASK
(Not supported
by CS1D CPU
Units for Duplex-
CPU Systems.)
MSKS
@MSKS
690
Output
Required
READ
INTERRUPT
MASK
(Not supported
by CS1D CPU
Units for Duplex-
CPU Systems.)
MSKR
@MSKR
692
Reads the current interrupt processing settings that were set with
MSKS(690).
Output
Required
Instruction
Mnemonic
Code
Symbol/Operand Function Location
Execution condition
GSBS(750)
N
N: Subroutine
number
GSBN(751)
N
N: Subroutine
number
GRET(752)
MSKS(690)
N
C
N: Interrupt number
C: Control data
Set scheduled interrupt
time interval.
Mask (1) or unmask (0)
interrupt inputs 0 to 7.
Time interval
Scheduled
interrupt
I/O
interrupt
Interrupt Input Unit 0 to 3
Sets up interrupt processing for I/O interrupts or scheduled interrupts.
Both I/O interrupt tasks and scheduled interrupt tasks are masked
(disabled) when the PC is first turned on. MSKS(690) can be used to
unmask or mask I/O interrupts and set the time intervals for
scheduled interrupts.
MSKR(692)
N
D
N: Interrupt number
D: Destination word
