319
Changing the Timer/Counter PV Refresh Mode Section 6-4
6-4-6 Instructions and Operands
Instructions
Instructions and Operands
Timer and Counter Instructions
HUNDRED-MS TIMER
TEN-MS TIMER
ONE-MS TIMER
Instruction
type
Name Mnemonic
BCD mode Binary mode
Timer and
Counter
Instructions
HUNDRED-MS TIMER TIM TIMX
TEN-MS TIMER TIMH TIMHX
ONE-MS TIMER TMHH TMHHX
TENTH-MS TIMER
(CJ1-H-R CPU Units only)
TIMU TIMUX
HUNDREDTH-MS TIMER
(CJ1-H-R CPU Units only)
TMUH TMUHX
ACCUMULATIVE TIMER (100 ms) TTIM TTIMX
LONG TIMER (100 ms) TIML TIMLX
MULTI-OUTPUT TIMER (100 ms) MTIM MTIMX
COUNTER CNT CNTX
REVERSIBLE COUNTER CNTR CNTRX
RESET TIMER/COUNTER CNR CNRX
Block program
instructions
TIMER WAIT (100 ms) TIMW TIMWX
HIGH-SPEED TIMER WAIT (10 ms) TMHW TMHWX
COUNTER WAIT CNTW CNTWX
Instruction name BCD mode Binary mode
Mnemonic TIM TIMX
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.1 s) 0 to 999.9 s 0 to 6,553.5 s
Instruction name BCD mode Binary mode
Mnemonic TIMH TIMHX
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.01 s) 0 to 99.99 s 0 to 655.35 s
Instruction name BCD mode Binary mode
Mnemonic TMHH TMHHX
S (timer set value) #0000 to #9999 (BCD) &0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
Setting time (unit: 0.001 s) 0 to 9.999 s 0 to 65.535 s
