xvi
Unit Versions and Programming Devices
The following tables show the relationship between unit versions and CX-Pro-
grammer versions.
Unit Versions and Programming Devices
Note 1. As shown above, there is no need to upgrade to CX-Programmer version
as long as the functions added for unit versions are not used.
2. CX-Programmer version 7.1 or higher is required to use the new functions
added for unit version 4.0 of the CJ1-H-R CPU Units. CX-Programmer ver-
sion 7.22 or higher is required to use unit version 4.1 of the CJ1-H-R CPU
Units. CX-Programmer version 7.0 or higher is required to use unit version
4.2 of the CJ1-H-R CPU Units. You can check the CX-Programmer version
using the About menu command to display version information.
3. CX-Programmer version 7.0 or higher is required to use the functional im-
provements made for unit version 4.0 of the CS/CJ-series CPU Units. With
CX-Programmer version 7.2 or higher, you can use even more expanded
functionality.
Device Type Setting The unit version does not affect the setting made for the device type on the
CX-Programmer. Select the device type as shown in the following table
regardless of the unit version of the CPU Unit.
Note When using a CJ1H-CPU@@H-R CPU Unit, set the CPU Unit model to
CPU67-R, CPU66-R, CPU65-R, or CPU64-R.
CPU Unit Functions (See note 1.) CX-Programmer Program-
ming
Console
Ver. 3.3
or lower
Ver. 4.0 Ver. 5.0
Ver. 6.0
Ver. 7.0
or higher
CS/CJ-series unit
Ver. 4.0
Functions added
for unit version 4.0
Using new functions --- --- --- OK (See
notes 2
and 3.)
No
restric-
tions
Not using new functions OK OK OK OK
CS/CJ-series unit
Ver. 3.0
Functions added
for unit version 3.0
Using new functions --- --- OK OK
Not using new functions OK OK OK OK
CS/CJ-series unit
Ver. 2.0
Functions added
for unit version 2.0
Using new functions --- OK OK OK
Not using new functions OK OK OK OK
CS1D CPU Units
for Single-CPU Sys-
tems, unit Ver. 2.0
Functions added
for unit version 2.0
Using new functions --- OK OK OK
Not using new functions
CS1D CPU Units
for Duplex-CPU
Systems, unit Ver.1.
Functions added
for unit version 1.1
Using function blocks --- OK OK OK
Not using function blocks OK OK OK OK
Series CPU Unit group CPU Unit model Device type setting on
CX-Programmer Ver. 4.0 or higher
CS Series CS1-H CPU Units CS1G-CPU@@H CS1G-H
CS1H-CPU@@H CS1H-H
CS1D CPU Units for Duplex-CPU Systems CS1D-CPU@@H CS1D-H (or CS1H-H)
CS1D CPU Units for Single-CPU Systems CS1D-CPU@@S CS1D-S
CJ Series CJ1-H CPU Units CJ1G-CPU@@H
CJ1G-CPU@@P
CJ1G-H
CJ1H-CPU@@H-R
(See note.)
CJ1H-CPU@@H
CJ1H-H
CJ1M CPU Units CJ1M-CPU@@ CJ1M
