Omron CJ - PROGRAMMING MANUAL 12-2009 - Page 192

152
Block Programming Instructions
Section 3-30
BLOCK
PROGRAM
RESTART
BPRS
812
Block program
Required
CONDITIONAL
BLOCK EXIT
EXIT
806
EXIT(806)
B: Bit operand
Block program
Required
CONDITIONAL
BLOCK EXIT
EXIT
806
EXIT(806)B
B: Bit operand
Block program
Required
CONDITIONAL
BLOCK EXIT
NOT
EXIT NOT
806
EXIT NOT(806)
B
B: Bit operand
EXIT(806) without an operand bit exits the program if the execution
condition is OFF.
Block program
Required
Instruction
Mnemonic
Code
Symbol/Operand FunctionS Location
Execution condition
N
BPRS
(812)
N: Block program
number
to
to
to
Block program n. This block
program will now be executed
as long as bit "a" is ON.
BPRS(812) executed
for block program n.
Pause and restart the specified block program from another block
program.
EXIT(806) without an operand bit exits the program if the execution
condition is ON.
Execution condition
Execution
condition
OFF
Execution
condition
ON
"A" executed. "A" executed.
"B" executed.
Block ended.
EXIT(806) without an operand bit exits the program if the execution
condition is ON.
Operand bit
OFF
(ON for
EXIT NOT)
Operand bit ON
(OFF for EXIT
NOT)
"A" executed. "A" executed.
"B" executed.
Block ended.
