xxi
About this Manual:
This manual describes the programming of the CPU Units for CS/CJ-series Programmable Controllers
(PLCs) and includes the sections described on the following page. The CS Series, CJ Series and NSJ
Series are subdivided as shown in the following figure.
Please read this manual and all related manuals listed in the table on the next page and be sure you
understand information provided before attempting to install or use CS/CJ-series CPU Units in a PLC
System.
NSJ-series Controller Notation
For information in this manual on the Controller Section of NSJ-series Controllers, refer to the
information of the equivalent CJ-series PLC. The following models are equivalent.
NSJ-series Controllers Equivalent CJ-series CPU Unit
NSJ@-TQ@@(B)-G5D CJ1G-CPU45H with unit version 3.0
NSJ@-TQ@@(B)-M3D CJ1G-CPU45H with unit version 3.0 (See note.)
Note: The following points differ between the NSJ@-TQ@@(B)-M3D and the CJ1G-CPU45H.
Item CJ-series CPU Unit
CJ1G-CPU45H
Controller Section in
NSJ@-@@@@(B)-M3D
I/O capacity 1280 points 640 points
Program capacity 60 Ksteps 20 Ksteps
No. of Expansion Racks 3 Racks max. 1 Rack max.
EM Area 32 Kwords × 3 banks
E0_00000 - E2_32767
None
Function blocks Max. No. of definitions 1024 128
Max. No. of instances 2048 256
CS1H-CPU@@H
CS1G-CPU@@H
CS1-H CPU Units
CS Series
CS1D CPU Units
CS1D CPU Units for
Duplex Systems
CS1D-CPU@@H
CS1D CPU Units for
Simplex Systems
CS1D-CPU@@S
CS1D Process-control CPU Units
CS1D-CPU@@P
CS1 CPU Units
CS1H-CPU@@(-V1)
CS1G-CPU@@(-V1)
CS-series Basic I/O Units
CS-series Special I/O Units
CS-series CPU Bus Units
CS-series Power Supply Units
Note: A special Power Supply Unit must
be used for CS1D CPU Units.
CJ-series Power Supply Units
CJ-series CPU Bus Units
CJ-series Special I/O Units
CJ-series Basic I/O Units
CJ1G-CPU@@
CJ1 CPU Units
CJ1M CPU Units
CJ1M-CPU@@
CJ1H-CPU@@H-R
CJ1H-CPU@@H
CJ1G-CPU@@H
CJ1G -CPU@@P
(Loop-control CPU Units)
CJ1-H CPU Units
CJ Series
NSJ Series
NSJ Controllers
NSJ5-TQ@@(B)-G5D
NSJ5-SQ@@(B)-G5D
NSJ8-TV@@(B)-G5D
NSJ10-TV@@(B)-G5D
NSJ12-TS@@(B)-G5D
NSJ Controllers
NSJ5-TQ@@(B)-M3D
NSJ5-SQ@@(B)-M3D
NSJ8-TV@@(B)-M3D
NSJ-series Expansion Units
CJ2H-CPU@@-@@@
CJ2 CPU Units
