Omron CJ - PROGRAMMING MANUAL 12-2009 - Page 70

30
Basic Concepts Section 2-1
Data Operand Data form Symbol Range Application example
16-bit con-
stant
All binary data or
a limited range of
binary data
Unsigned binary # #0000 to #FFFF MOV #0100 D00000
Stores #0100 hex (&256 dec-
imal) in D00000.
+#0009 #0001 D00001
Stores #000A hex (&10 deci-
mal) in D00001.
Signed decimal ± –32768 to
+32767
MOV −100 D00000
Stores −100 decimal (#FF9C
hex) in D00000.
+−9 −1 D00001
Stores −10 decimal (#FFF6
hex) in D00001.
Unsigned deci-
mal
& (See Note.) &0 to &65535 MOV &256 D00000
Stores −256 decimal (#0100
hex) in D00000.
+&9 &1 D00001
Stores −10 decimal (#000A
hex) in D00001.
All BCD data or a
limited range of
BCD data
BCD # #0000 to #9999 MOV #0100 D00000
Stores #0100 (BCD) in
D00000.
+B #0009 #0001 D00001
Stores #0010 (BCD) in
D00001.
32-bit con-
stant
All binary data or
a limited range of
binary data
Unsigned binary # #00000000 to
#FFFFFFFF
MOVL #12345678 D00000
Stores #12345678 hex in
D00000 and D00001.
Signed binary + –2147483648 to
+2147483647
MOVL −12345678 D00000
Stores −12345678 decimal
in D00000 and D00001.
Unsigned deci-
mal
& (See Note.) &0 to
&429467295
MOVL &12345678 D00000
Stores &12345678 decimal
in D00000 and D00001.
All BCD data or a
limited range of
BCD data
BCD # #00000000 to
#99999999
MOVL #12345678 D00000
Stores #12345678 (BCD) in
D00000 and D00001
1234 5678
D0001 D00000
