Alarm 1 type
Alarm 2 type
Alarm 3 type
Conditions of Use
Alarms must be assigned as outputs. For
example, if alarm output 1 and 2 only are
assigned as outputs, the “alarm 3 type”
parameter cannot be used.
Ă• Alarm 1 to 3 type" parameters specify the operation of the alarm by the one of the
set values in the following table. For details of operation at an alarm, see page 3Ć10.
Set Value Settings Set Value Settings
1
Upper- and lower-limit alarm
7 Lower-limit alarm with standby sequence
2 Upper-limit alarm 8 Absolute-value upper-limit alarm
3 Lower-limit alarm 9 Absolute-value lower-limit alarm
4 Upper- and lower-limit range
alarm
10 Absolute-value upper-limit alarm with
standby sequence
5 Upper- and lower-limit alarm with
standby sequence
11 Absolute-value lower-limit alarm with
standby sequence
6 Upper-limit alarm with standby
sequence
Default is 2 : upper limit".
ĂRelated description
3.4 Setting Alarm Type (page 3Ć10)
ĂRelated parameters
Alarm value 1" Alarm value 2" Alarm value 3" (Program mode)
Alarm 1 hysteresis" Alarm 2 hysteresis" Alarm 3 hysteresis" (level 2 mode)
Alarm 1 open in alarm" Alarm 2 open in alarm" Alarm 3 open in alarm" Control
output 1 assignment" Control output 2 assignment" Auxiliary output 1 assignĆ
ment" (setup mode)
