Auxiliary output 1 assignment
Ă• Assigns output functions to auxiliary output 1.
The following 10 output functions can be assigned as outputs:
Alarms 1 to 3, LBA, Time signals 1 to 2, Program end, Stage output, Error 1 (input
error), Error 2 (A/D converter error)
Ă• When the output function assigned to auxiliary output 1 is ON, the SUB1 LED lights.
Symbol to
to
Function Alarms 1 to 3 LBA Time signals 1 to 2
Symbol
Function Program end Stage output Error 1 Error 2
These parameters are factoryĆset to [ ].
ĂRelated description
3.3 Setting Output Specifications (page 3Ć7)
ĂRelated parameters
Ă• AlarmĆrelated parameters
Time signal 1 enabled step" Time signal 2 enabled step" Time signal 1 to 2 ON
time" Time signal 1 to 2 OFF time" (program mode)
LBA detection time" (level 2 mode)
Setup Mode
Function
Setting
See
