E5CK
5–37
Set point upper limit
Set point lower limit
Ă• Limits the upper and lower limits when the SP is set. The SP can be set within the
range defined by the upper and lower limit set values of the set point upper limit"
and set point lower limit " parameters. Note that as these parameters are reset, the
SP of existing settings that are out of the range are forcibly changed to one of the
upper or lower limit values.
Ă• When the temperature input type and temperature unit have been changed, the set
point upper limit and set point lower limit are forcibly changed to the upper and
lower limits of the sensor.
Ă• During temperature input, the decimal point position is dependent on the currently
selected sensor, and during analog input on the results of scaling.
Parameter Setting Range
Unit Default
Set point upper limit Set point lower limit +1 to scaling upper limit EU 1300
Set point lower limit Scaling lower limit to set point upper limit -1 EU -200
During temperature input, the range becomes the range of use of the selected sensor
instead of the range defined by the scaling upper and lower limit values.
ĂRelated description
4.2 Operating Condition Restrictions (page 4Ć7)
ĂRelated parameter
Input type" Scaling upper limit" Scaling lower limit" Decimal point" (setup
mode)
PID/ON/OFF
Ă• Selects advanced PID control or ON/OFF control.
Setting Range
Default
“ ” :Advance PID/ “ ” :ON/OFF
ĂRelated description
4.1 Selecting the Control Method/ON/OFF control (page 4Ć5)
ĂRelated parameters
Hysteresis (heat)" Hysteresis (cool)" (level 1 mode)
Expansion Mode
Function
Setting
See
Function
Setting
See
To Next Page
