Omron E5CK User Manual

1.1 Names of parts
E5CK
1–3
JAbout the displays
Displays the process value or parameter symbols.
Displays the set point, manipulated variable or parameter settings.
Ă• OUT1
Lights when the pulse output function assigned to control output 1" is
ON.
Ă• OUT2
Lights when the pulse output function assigned to control output 2" is
ON.
Ă• SUB1
Lights when the pulse output function assigned to auxiliary output 1"
is ON.
Ă• MANU
Lights in the manual operation mode.
Ă• RST
Lights when the control is in reset status.
Ă• RMT
Lights during remote operation.
Ă• AT
Flashes during autoĆtuning.
F No.1 display
F No.2 display
F Operation status
indicators

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
