CHAPTER 6 USING THE COMMUNICATIONS FUNCTION
E5CK
6–14
Parameter No. Parameter Data Setting and Monitor Range Mode
41 Step 14 SP SP lower limit to SP upper limit
42 Step 14 time 0.00 to 99.59
43 Step 15 SP SP lower limit to SP upper limit
44 Step 15 time 0.00 to 99.59
04 Pattern execution count 0 to 9999
45 Time signal 1 enabled step 0 to 15
Program
46 Time signal 1 ON time 0.00 to 99.59
g
47 Time signal 1 OFF time 0.00 to 99.59
48 Time signal 2 enabled step 0 to 15
49 Time signal 2 ON time 0.00 to 99.59
50 Time signal 2 OFF time 0.00 to 99.59
62 Standby time 0.00 to 99.59 Level 2
54 Operation at power ON *3
55 End condition 0: Reset, 1: Final step SP
61 Number of patterns 1 to 4
51 Program time unit 0: Hour, minute, 1: Minute, second
56 Step time/Rate of rise programming 0: Step time, 1: Rate of rise programming
Expansion
57 Time unit of ramp rate 0: Minute, 1: Hour
p
58 PV start 0: SP start, 1: PV start
52 Alarm during ramp step enable 0: OFF, 1: ON
53 Run all enable 0: OFF, 1: ON
*3 0: Continue, 1: Reset, 2: Run, 3: Manual

Omron E5CK Specifications

General

Ambient Operating Temperature	-10 to 55°C
Protection Rating	IP20
Control Type	PID
Input Type	Thermocouple, RTD
Output Type	Relay, Voltage, Current
Power Supply Voltage	100 to 240 VAC
Mounting Type	Panel
Display Type	Digital
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Dimensions	48 x 48 x 78 mm
Ambient Operating Humidity	25% to 85% RH
